Audia Flight - FLS10 - Stereo Integrated Amplifier
The FLS10 is a high-end integrated amplifier that offers exceptional performance and versatility. At its core is the FLS4 power amplifier, which incorporates advanced technology to deliver speed, power, driving capability, and precise control. Here are the key features and details of the FLS10:
-
Powerful Amplification: The FLS10's power amplifier shares the same technology as the FLS4 power amplifier, ensuring outstanding speed, power, and control. It features a fully balanced circuitry and 32 power devices, providing a robust and dynamic sound.
-
High-Quality Components: The amplifier is built with carefully selected components to ensure the best audio quality. It boasts a power supply with extra-low impedance and high-quality capacitors, including 288,000µF capacitors on the main power supplies.
-
Versatile Connectivity: The FLS10 is compatible with a wide range of speakers, including less efficient, impedance-critical, and low-ohm loudspeaker systems down to 2 ohms. This versatility allows you to connect various types of speakers with confidence.
-
Balanced Preamplification: The preamplification section of the FLS10 is fully balanced and offers a high-end volume control in a dual mono configuration. It provides both XLR and RCA outputs, as well as a REC RCA (fixed level) output. Additionally, the amplifier features three RCA inputs and two XLR inputs.
-
Customizable Inputs: All inputs can be easily activated or deactivated, and the gain can be adjusted with a range of +/- 6dB. You can also rename each input to suit your preferences, offering a personalized listening experience.
-
Premium Design: The FLS10 boasts a full brushed aluminum chassis with the "Audia Flight" logo engraved on the top cover, showcasing attention to detail and aesthetics. It comes with an aluminum remote control that is both brushed and anodized, enhancing the overall appearance. The OLED blue display adds a touch of sophistication to the amplifier.
-
Expandable Options: The FLS10 offers expandability through optional plug-and-play cards. These optional cards include:
- MM and MC unbalanced inputs phono board.
- RCA board with two additional RCA inputs.
- DAC board featuring one asynchronous USB input (with Galvanic isolation) supporting 32-bit 384KHz and DSD 512, as well as four digital inputs (2x optical, 1x AES/EBU, 1x SPDIF) with 32-bit, 192KHz support (also with Galvanic isolation).
The Audia Flight FLS10 integrated amplifier is designed to provide a superior and customizable audio experience, making it an excellent choice for high-end audio enthusiasts.
| Technical Specifications | Specifications |
|---|---|
| Output Power per Channel (Wrms) | 200/380/700 (8/4/2 ohm) |
| Inputs | 3 unbalanced (RCA), 2 balanced (XLR) |
| Outputs | 1 unbalanced (RCA), 1 balanced (XLR), 1 REC unbalanced (RCA) |
| Gain Range | -90dB / +10dB |
| Gain Resolution | 0.5dB |
| Frequency Response (-3dB) | 0.3 Hz ÷ 500 KHz |
| THD | < 0.05% |
| Signal-to-Noise Ratio (S/N Ratio) | 110 dB |
| Input Impedance | 47 Kohm |
| Damping Factor (on 8 ohm) | > 650 |
| Main Voltage AC (50-60Hz) | 100, 110-115, 220-230, 240 V |
| Stand-by Power Consumption | Less than 1 W |
| Power Consumption | 840W (200W RMS @ 8 Ohm both channels) |
| Dimensions (W x H x D) | 450x180x440mm |
| Weight | 36kg |
| Shipping Dimensions (W x H x D) | 575x310x545mm |
| Shipping Weight | 46kg |
