Marantz - AMP20 - Reference AV Amplifier
AMP 20 is a remarkably powerful 12-channel amplifier, and can be paired with AV 20 for an elite, reference-level home theatre system.
- Crafted in Shirakawa, Japan
- 12 Channels
- 200 Watts per Channel
- Exclusive HDAM
- Custom Switching Amplifiers
- Selectable Output Modes
Ultimate Performance
AMP 20 combines very high-power output and high channel count to create a master reference-level amplifier for ultimate home theatre performance. When paired with AV 20, the results are unforgettable.
- Ultimate Performance - AMP 20’s custom-developed Class D amplification and refined HDAM-SA2 technology create the most incredible theatrical experience possible in your home.
- Sound Master Tuned - Marantz' Sound Master meticulously tuned AMP 20 for amazing performance with careful parts selection to create outstanding sound in your home.
- Effortlessly Powerful - AMP 20 gives you 12 channels of commanding power in a single enclosure, each rated at 200 watts to perform at extraordinarily high levels with no loss in fidelity.
- System Matching - Make sure you get the best possible performance from your AMP 20 by combining it with other Marantz products – such as the AV 20.
Specifications
Inputs & Outputs
- Main Amplifier in: Balanced & Unbalanced: 12ch (Exclusive use by a selector switch.)
- Speaker Terminal: SPKT-1+
- Number of Speaker Terminals: 12
- Bi-Amp Drive /BTL Drive: Yes / Yes
- Level Meter: Yes
- Chassis: Copper Plated
Multi-Room CI
- RS232 Control: Yes
- IR Flasher In: Yes
- Marantz Remote Bus: Yes
- DC Trigger Input/ Output: 1 / 1
Other
- Number of poweramps: 12
- Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL: 200W / 400W
- Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal: 400W
- Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal: 200W
General
- Front Display: Level Meter
- Auto Power Off: Yes
- Metal Front Panel: Yes
- Power Consumption: 400W
- Power Consumption, No-Sound: 110W
- Standby Consumption: 0.2W
- Maximum Dimensions (W × D × H): 17.4 × 17.4 × 7.5 in.
- Weight: 39.7 lbs
- What's in the box: Main unit, quick start guide, AC cord,Amp control cable, Remote control cable, SP terminal wrench
- UPC code: 747192143930
